Bring composable-infrastructure economics to enterprise datacenters — pool endpoints, reallocate on demand, consolidate multiple workloads on one shared fabric.
A PCIe Gen4 fabric backplane that lets your IT team pool GPUs, NVMe, NICs, and FPGAs — and reassign them across workloads without recabling.
For enterprise datacenters running a mix of workloads (AI, analytics, databases, virtualisation), composable PCIe eliminates the over-provisioning tax. Buy the endpoints once. Route them wherever demand is.
The block diagram lays out the composable Enterprise PCIe Infrastructure. Multiple host servers each carry a PCIe HBA that connects into a shared Gen4 switch fabric. Behind the fabric sits a pool of PCIe endpoints — NVMe, GPU, DPU, or custom accelerator cards — that any host can claim on demand. A control plane (running on the same or an adjacent management node) enforces zoning, hot-plug, and telemetry. Utilisation of expensive accelerators is driven up; hardware refresh cycles move from server-level to endpoint-level.
The connection diagram shows the DF-S07 wired into an enterprise rack. Each participating host runs an MCIO cable to the switch chassis. External endpoints (JBOF, GPU box, DPU shelf) uplink to the same chassis. A dedicated management network reaches the control plane for zoning changes. A+B power feeds keep the fabric hot during PDU maintenance. Use this diagram to plan host-to-fabric cable topology, HBA placement, and control-plane network segmentation.
| Interface | Details |
|---|---|
| Host lanes | Multiple PCIe Gen4 x16 upstream |
| Endpoints | GPU, NVMe, NIC, FPGA (mixed) |
| Binding | Software-defined |
| Multi-tenancy | Enforced per binding policy |
| Management | DCIM-native · Redfish |
Enterprise IT lives with a hard trade-off: over-provision every server for worst-case workloads and waste hardware, or under-provision and hit performance ceilings during bursts. Composable PCIe removes the trade-off.
The Datafabrix Enterprise PCIe Infrastructure solution places a Gen4 fabric backplane at rack scale. GPUs, NVMe drives, high-speed NICs, and FPGAs live in a shared pool. Servers connect via cabled PCIe upstream lanes. Software policy binds endpoints to hosts as workloads demand.
The result: buy fewer GPUs, get more useful work out of them. Buy fewer NVMe drives, use them harder. Buy fewer NICs, saturate them under bursty workloads.
Cut hardware spend by 30–50% via shared endpoint pools.
Reassign hardware to whichever workload needs it now.
Give teams elastic access to a shared hardware pool.
| Category | Specification |
|---|---|
| Fabric | PCIe Gen4 non-blocking · rack-scale |
| Upstream | Multiple PCIe Gen4 x16 |
| Endpoint types | GPU, NVMe, NIC, FPGA (mixed) |
| Orchestration | Software-defined binding |
| Management | DCIM-native |
Where it fits in the rack, how it connects, and what you get after installation.
Composable enterprise PCIe fabric for large IT teams standardizing on software-defined infrastructure. The solution slots into a standard 19-inch rack alongside your existing servers, storage, and network fabric — no re-architecture required.
Target deployments: Enterprise IT organizations moving from static servers to composable infrastructure.
Slide the DF-S07 chassis into a standard 19-inch rack slot. Rail kit included. Cable to your PDU and management network.
Install the Datafabrix PCIe host adapter in your existing server. Connect via PCIe cable to the DF-S07 backplane uplink.
Insert NVMe drives, GPUs, or accelerators into hot-plug slots. Each device trains and appears as a native PCIe endpoint on the host.
Optional: connect to Datafabrix DCIM for fleet-wide visibility. Add more chassis for horizontal scale — no host reconfiguration.
Direct rack integration alongside your existing production servers. Turnkey in a single deployment window.
Scale from a single chassis pilot to full-rack production with zero architectural change.
OEM-ready configuration for organizations building their own branded infrastructure products.
Engineering pilots, reference designs, and OEM co-design programs — we work with your team from concept to production.
